Dynamic Pile Analyzer -GPC

About Dynamic Pile Analyzer -GPC

Piletests GPC is the next generation of dynamic pile testing systems It is designed with simplified software and higher ease of use than past systems

The GPC system was designed with Professor George G Goble the pioneer of dynamic pile analyzers The GPC complies with ASTM D4945  Standard Test Method for HighStrain Dynamic Testing of Deep Foundations and Eurocode EN ISO224774

To test a pile you need to connect only two dualpurpose sensors to it The system box can be attached to the pile under test and via a lossless wireless communication sends all the monitored data to your computer This concept makes the construction site work much easier and faster to operate

To measure four 4 sides of a pile two main box systems can be operated concurrently with a dual WiFi connection computer The collected data is processed by three 3 stateoftheart sw packages

Efficient Foundation Assessment

With realtime data acquisition and high precision the Dynamic Pile Analyzer  GPC streamlines pile quality assessments ensuring reliable results in outdoor environments Its portable semiautomatic control and digital display facilitate straightforward usage for site engineers and technicians

Advanced Technology Integration

The analyzer incorporates a piezoelectric transducer and offers wireless data transfer supported by Windowscompatible software Data can be stored internally 64 MB transferred via USB or RS232 and analyzed immediately enhancing productivity and decisionmaking onsite

Durability and User Convenience

Constructed for rugged environments this equipment withstands humidity up to 90 RH and temperatures from 0C to 40C Its portable build and included accessories like carrying case cables and chargers make transportation and setup at construction sites practical and efficient

FAQs of Dynamic Pile Analyzer GPC

Q How does the Dynamic Pile Analyzer GPC assess foundation pile quality

A The analyzer performs dynamic testing using an 8 kg impact hammer and sensors to measure acceleration and strain in piles Data is collected via piezoelectric transducer and analyzed for parameters such as integrity bearing capacity and defects supporting accurate pile quality assessments

Q What is the process for data acquisition and storage

A During each test signals are captured and digitized then stored in the 64 MB internal memory Data can be transferred wirelessly and processed using Windowscompatible software allowing realtime analysis and easy management of test results

Q When and where should this equipment be used

A The Dynamic Pile Analyzer is designed for use at outdoor construction sites during foundation pile installation and assessment It is suitable for environments with humidity up to 90 RH and temperatures ranging from 0C to 40C making it ideal for field operations

Q What are the benefits of its wireless communication and digital display

A Wireless data transfer facilitates remote monitoring reducing onsite cables and setup time The LCD digital display offers immediate visibility of test results enabling quick decisionmaking and improving workflow efficiency during pile testing

Q How is calibration managed for this analyzer

A Each unit is factory calibrated to ensure precision and reliable measurements eliminating the need for frequent user calibration Calibration certificates and documentation are provided with the equipment for compliance and quality assurance

Q How do users power and operate the analyzer at a construction site

A The device operates on a standard 220V AC 50Hz power supply Users simply mount the specimen connect the portable handheld unit and initiate tests with digital controls following the semiautomatic process for consistent results
